SPECIFICATIONS
Material :Aluminum
LED: Citizen/Cree/Philips/Sanan
LED Driver : Philips/Osram/HEP/Lifud
Dimmable : Triac/0-10v/DALI/ RF Dimming
Diffuser: Optical Reflector , efficiency≥90%
Adaptor : Three Phases ,One Phase
| Model No.: | Power | CRI | CCT | Lumen EEF | Lumen(lm) | Beam Angle | Input voltage | Size(mm) | Packing(cm) |
| EL-G29007 | 7W | ≥80 | 5000k | 90lm/w | 700lm | 12°/23°/36° | 220-240v 50-60Hz | 139*45*124 | |
| EL-G29012 | 12W | ≥80 | 5000k | 90lm/w | 1200lm | 12°/23°/36° | 220-240v 50-60Hz | 139*53.5*128 | |
| EL-G29020 | 20W | ≥80 | 5000k | 90lm/w | 2000lm | 12°/23°/36° | 220-240v 50-60Hz | 179*64.5*139 | |
| EL-G29030 | 30W | ≥80 | 5000k | 90lm/w | 3000lm | 12°/23°/36° | 220-240v 50-60Hz | 179*75*150 |
Application:
Commercial Area ,Clothing stores, luxury stores, museums, supermarket chains, Hotel ,auto 4S shops, high-end office space, etc.
